Aluminium Jacket with Polycraft

Description

Aluminum Jacketing with polycraft moisture barrier is manufactured from wrought aluminum alloy 1060, 3003 or 5005 meeting ASTM standard B209 with H14 and H16 temper. The properties of these aluminum alloys provide the required strength to resist in-service abuse, but can be easily fabricated and installed. PKMB- POLYKRAFT MOISTURE BARRIER makes aluminum jacketing suitable for most general industrial applications. It will keep your insulation dry and functional. Aluminum jacket has a moisture Retarder. The retarder prevents galvanic or chemical corrosion at the metal-insulation interface.
1.Grade: 1006, 1100, 3003, 3105, 5005
2.Temper: O, H12, H14, H16, H24, etc.
3.Common use: 3003 H14 H16, 1100 H14 H16, 5005 H14
4.Type: Coil roll Application: Industrial insulation jacketing, cover, insulation protective jacketing
5.Thickness: 0.3-1.5mm
6.Width: 914mm, 1000mm, 1219mm
7.Length: 20, 25,30, 60, 90m per roll or as per clients
8.Surface Treatment: Plain, Flat, mill finish, Embossed
9.Moisture barrier: poly craft paper, kraft paper
10.Kraft-paper: 166g/m2
11.Color: khaki
12.Certificate: ISO9001, GB/T3880, ASTM B209
13.Packaging: packed in carton or coil in wooden pallet
14.Delivery time: 25-45 days
● Refer attachment for product specification
