Description
7075 aluminum is a kind of cold treatment forging alloy with high strength and hardness, far better than mild steel. 7075 aluminum is one of the most powerful commercial alloys. It has common corrosion resistance, good mechanical properties and anodic reaction. The fine grain makes the deep drilling performance better, the tool wear resistance enhanced, the thread rolling more different, the density requirement is smaller, the hardness requirement is higher.
7075 alloy belongs to Al Zn mg Cu super hard aluminum. It has been used in aircraft manufacturing industry since the late 1940s and is still widely used in aviation industry. It is characterized by good plasticity after solution treatment, especially good heat treatment strengthening effect, high strength below 150 ℃ and especially good low temperature strength; The welding performance is poor; There is a tendency of stress corrosion cracking; It needs to be protected by aluminum coating or other treatment. Two stage aging can improve the stress corrosion cracking resistance of the alloy. The results show that the plasticity of the annealed and quenched sheet is slightly lower than that of 2A12 and better than 7A04. The static fatigue, notch sensitivity and stress corrosion resistance of the sheet are better than those of 7A04. Among them, 7075-T651 is the best product in aluminum alloy with high strength and far better than soft steel. The alloy has good mechanical properties and anodic reaction, and is a typical aluminum alloy material for aerospace and military industry.
Main Applications for 7075 Aluminium
Aerospace industry, blow molding (bottle) mold, ultrasonic plastic welding mold, golf head, shoe mold, paper plastic mold, foaming mold, dewaxing mold, template, fixture, mechanical equipment, mold processing, used to make high-end aluminum alloy bicycle frame.
7075 status: O, T6, T73, T76 plate.
7075 status: O, t651, t7351, t7651 thick material
7075 status: O, T6, t173 stretch tube
7075 status: O, T6, t6510, t6511, T73, t73510, t73511, T76, t76510, t76511 extruded tube, shape, rod and wire
7075 status: O, H13, T6, t651, T73, t7351 rolled or cold worked bar
7075 status: O, H13, T6, T73 cold worked wire rod
7075 status: T6, T73 rivet wire
7075 status: F, T6, t652, T73, t7352 forgings
Characteristic for 7075
1. High strength heat treatable alloy.
2. Good mechanical properties.
3. Good usability.
4. Easy processing and good wear resistance.
5. Good corrosion resistance and oxidation resistance.
7075 is an aluminum alloy with zinc as the main alloying element, but sometimes a small amount of magnesium and copper are added. Among them, super hard aluminum alloy is a kind of alloy containing zinc, lead, magnesium and copper, which is close to the hardness of steel and can be strengthened by heat treatment. It is a high strength and heat treatable alloy with ordinary corrosion resistance and good mechanical properties. Aluminum 7075 is a cold treatment forging alloy with high strength, far better than mild steel. 7075 aluminum alloy is one of the most powerful commercial alloys. General corrosion resistance, good mechanical properties and anodic reaction. The fine grain makes the deep drilling performance better, the tool wear resistance enhanced, and the thread rolling is more different from the heavy one.
● Refer attachment for product specification
