Anodized Aluminium Panel

By: Taizhou Naze New Material Co., Ltd

Price	Available on request
Category	Building and Construction Extrusion
Manufacturer	Taizhou Naze New Material Co., Ltd.
Min Order Quantity	10.00 MT
Delivery Lead Time	As per order
Place of Origin	China
Supply Ability	Customization as required
Packaging Details	Standard export packing
Transportation Details	Road / Ship

Send response to similar sellers

Details

Valid Upto

18.07.2025

Description

Anodized Aluminium Panel is an aluminum material with a certain thickness of oxide layer on the surface after special treatment. This process can prepare aluminum plate material with a uniform surface, wear resistance, corrosion resistance, and beautiful appearance, which is widely used in the fields of construction, electronics, automobiles, etc.

Technical Data:

Technical Properties	Standards	Anodized
Alloy	EN 573-3	A5005
Temper	EN 515	H24
Standard Thickness	EN 485-4	1mm-3mm
Standard Widths	EN 485-4	600mm, 1000mm, 1250mm, 1500mm
Standard Length	EN 485-4	≤ 4000mm
Panel Weight		1mm = 2.7Kg/m2
		2mm = 5.4Kg/m2
		3mm = 8.1Kg/m2
Tensile Strength	EN 1396	140 – 230MPa
Coating Thickness	EN 13523-1	15 - 25 µm
Fire Classification	EN 13501-1	A1
