Automatic Stacker

Automatic Stacker

By: Ungar Machinery (Shanghai) Co., Ltd.
Price Available on request
Category Equipment
Manufacturer Ungar Machinery (Shanghai) Co., Ltd.
Min Order Quantity 1.00 Unit
Delivery Lead Time As per order
Place of Origin China
Supply Ability Customization as required
Packaging Details Standard export packing
Transportation Details Road / Ship

Details

14.12.2024

Description
 Collector belt width 600mm(45ton)/850mm(63ton)/1080mm(80ton)/1340mm(110ton)
 Collector belt heihgt 1100+-100mm (According press machine's size, we will adjustable height system on requested)
 Min. container dimensions 80 x 120mm(Smaller on request)
 Container dimensions 450 x 340mm(1 lane) 230 x 340mm(2 Lines)
The lanes could be less or more on your condition, also depend on container shape.
 Max. height of container stack 300mm(Depend on the container shape and size)
 Lifting system By step motor and linear guide
 Photocell electronic counting device Container counter automatically stops press at top of stroke in emergency situations.
 Control panel Touch screen panel
 Stacking system Photo electric sensor controls the height of the stack with electric brake system.
 Installed Power 1Kw
 Air consumption(2lanes) 0.1m3/Min
 Net.weight 300kg
 Stacker dimensions(L*W*H) 55ton:3200x1050x1400(+-100mm)mm;
63ton:3200x1300x1400mm;
80ton:3200x1530x1400mm;
110ton:3200x1790x1400mm

Other Products

Aluminium Foil Box Folding Machine

Aluminium Foil Box Folding Machine

By: Ungar Machinery (Shanghai) Co., Ltd.

Auto Rewinding Machine

Auto Rewinding Machine

By: Ungar Machinery (Shanghai) Co., Ltd.

Scrap Press
