Second Hand Strip Stretching and Degreasing line

By: Alcircle Pte Ltd

Price	USD 293741.25
Manufacturer	Lenze / Eisenmann / Fröhling / Redex
Built	1986
Functions	Trimming / stretching / rewinding / chemical degreasing / middle cut
Production speed (Max)	120 m/min
Width	600 - 1600 mm
Thickness	60 - 500 µm
Unwinding dimensions	max.6.2 t / max.Ø 1700 mm
Unwinding tension	0.5 - 10 kN
Spools	Q1,M70, Q3, Steel & cardboard sleeve
Rewinding dimensions	Max. 3.1 t / max. Ø 1200 mm
Rewinder tension	0.5- 10 kN Winder DC Engine
Category	Equipment
Manufacturer	Daehyun Tech Co
Min Order Quantity	1.00 Unit
Place of Origin	Germany

Send response to similar sellers

Details

Valid Upto

10.04.2025

We have a sale offer of second-hand strip stretching and degreasing line.

Other Features:

Stretching level	0.1 - 2.8
Stretching force	0 - 120 kN
Annual capacity	8800 t/a (19 Shifts/week)
Required space	Approx. 700 m²
Operation direction	From right to left (for the complete machine)
Trimming Section	Trimming Roller knife, Spring knife
Thickness	120 - 500 µm, 70 - 120 µm
Width	800 - 1600 mm, 750 -1500 mm
Min. trimming	10 mm on each side
Max. trimming	60 mm on each side , 40 mm on each side
Middle cut	No
Main components	4 deflection rolls stretching section
Strip width	500 - 1500 mm
Strip thickness	0.04 - 0.5 mm
Speed	0 - 200 m/min
Deflection roll diameter	600 mm
Barrel length	1600 mm
Max allowed wear on the roll surfaces	3 mm as sum the diameter of all rolls -12 mm as max. for on single roll
Entrance & exit min. tension	150 daN
Entrance & exit max.tension	1000 daN
Max. stretching tension	12000 daN
Stretching level	Adjustable from 0% to 2 %
Gear box supplier	Redex Drive
Power	1 x 120 kW
